Radio Shack TRS-80 Model 4 (Dual Boot Rom/128k/FreHD)

October 5th, 2019 1 comment
Radio Shack TRS-80 Model 4 (Dual Boot Rom/128k/FreHD

I received as a gift… we start badly,i have recover, we are not there, i purchased, much better, yet another computer from Radio Shack that was missing in my collection.

The computer equipped with several manuals and Floppy Disk was given to me by a dude (thanks Scott) from the United States, he had written “near mint” and is this phrase that attracted me.

The Computer is a Radio Shack TRS-80 Model 4 (GATE ARRAY) therefore of last production with cathode ray tube with green phosphors.

The seller was not joking saying that it was “near mint” and working, the computer is kept very well it almost seems like it has never been used, it can be observed from the cathode tube, from the pcb of the monitor and from the flyback transformer, keyboard, External and internal Case and from the power supply, the usual ASTEC, which has never warmed up, perfect.

The warranty sticker was also intact.

Since there was nothing to clean/repair i have made some hardware enhancements and little replacements.

What i have done:

  • Replacement of the 3 filter capacitors (RIFA) which i usually remove and i don’t replace.
  • Converted the ASTEC power supply from 115V to 230v because this version of the power supply allows it because has a 115v/230v switching.
  • Replaces the 115v power plug with a schuko.
  • Various labels to identify the computer has been converted to 220v.
  • Installed 64k RAM to update the Model 4 to 128k (blue wire mod as well)
  • Dual ROM to BOOT from FreHD or from Floppy Drive. I have used the Jim Brain ROM-el 2364 which uses a Flash ROM (AT49F001AN) but with a standard Mask ROM 2364 pinout.
  • Installed a switch for Dual ROM hidden in the ventilation slots without drilling the case.

All test are made with the FreHD interface by Ian Mavric.

Gallery:

Download: TRS-80 M4 GA Dual Boot ROM (610)

Hoxs64 Commodore 64 Emulator Updated v1.0.23

October 1st, 2019 1 comment

Hoxs64 written by David Horrocks is a Commodore 64 emulator for Microsoft Windows 2K/XP/Vista/Seven (DirectX 9+)

The emulator substantially reproduces this legacy machine in minute detail.

Changelog (v1.0.23):

  • Allow PC joystick to control up to 5 C64 keys.
  • Monitor refresh option added to emulation video settings.

Download:

source: hoxs64.net

C64 Big Game Pack: Croaky +2HF / Trogue64 +5H / X-Out +6DGI…

September 21st, 2019 No comments

NEW TAG: C64 BIG GAME PACK

Some new games or tools (Cracked / Trained or Unrealeased) for Commodore 64 have been released from your favorites groups.

Titles:

  • Spaceware Shuttle Designer
  • Stercore XD +1D
  • Stercore 64 +1D
  • Endless Forms Most Beautiful 64 +
  • C64 Chess Preview
  • Numen Engine Preview
  • Endless Forms Most Beautiful 64 +3D
  • Swarm 16k V1.1.0
  • Endless Forms Most Beautiful 64 V1.1 +3D
  • Swarm 16k V1.1.0 &D
  • Forgotten Worlds +13DI
  • SIDWAVE Shooter [seuck]
  • 4M Arena [disk]
  • LVDVS Preview
  • Wug +
  • Killer Bees V4 +2HF
  • X-Out +6DGI
  • War2One Preview
  • Donkey Trolls Preview +3H
  • Railroad Tycoon +D
  • Racing Destruction Set
  • Racing Destruction Set [easyflash]
  • Berks Four
  • Berks Four +3
  • Minesweeper 2019
  • Spider Maze Tutorial Preview +
  • Testgame Preview +
  • Let’s Make a C64 Game Preview
  • Stay Alive +M
  • Chopper Command +D
  • Chopper Command
  • Chopper Command +1D
  • Chopper Command +3D
  • Helicopter Game Preview
  • TRogue64 Preview +3DF
  • Duel Intro +1HF
  • Berks Four V1.1
  • Swarm 16k V1.1.0 +D
  • Desatranques Jaén [seuck]
  • 4M Arena +3 [disk version]
  • Masquerade +D
  • Budokan +3DFI
  • Beat Em Up Preview 2 +
  • SplatThem64
  • SplatThem64 +
  • Happy Blocks DX
  • 4 A Win
  • Bombakereső +D
  • Bombakereső +CD
  • Happy Blocks DX +2D
  • Bombakereső (minesweeper)
  • Bombakereső +1D
  • 4 A Win +F
  • Cruiser-X 79 Preview +2D
  • Cimbo +D
  • Cimbo +
  • Banana Republic Preview +3D
  • Cimbo +1D
  • Cruiser-X 79 Preview +2D
  • Mafia Assembler Edition Preview [german]
  • Cimbo
  • Lhasa Mountain +D
  • Dragon Hunter +2D
  • Crypt of the Pharaoh +D
  • Brick’s Revenge Preview +2
  • Mafia Assembler Edition Preview
  • Mr T’s Money Box +D
  • Mr T’s Alphabet Games +D
  • Mr T Meets His Match +D
  • Mr T’s Number Games +D
  • Mr T’s Shape Games +D
  • Mr T’s Measuring Games +D
  • Dragon Hunter +2D
  • Croaky +2
  • Croaky +2HF
  • The Temple of Doom +3FD
  • Trogue64 +5H
  • Rockball +2D

Download: All Games in One Archive (5753)

source: csdb.dk

Categories: C128/128D/128DCR, C64/SX64, DTV

This Commodore 16 has seen better days

September 19th, 2019 No comments
This Commodore 16 has seen better days

This repair was done only for a personal challenge, the computer is still unstable and with several died components.

After a careful cleaning the computer presents these problems:

  • TED MOS 8360R2 not working (keyboard doesn’t work) even if i replace the TED doesn’t work, TED also tested on a working C16 doesn’t work.
  • PIO MOS 6529 need to be replaced. The keyboard doesn’t work.
  • CPU MOS 8501 Dead.
  • Joystick ports (see photo)
  • Cartridge connector need to be replaced.
  • Modulator without lids (Above and Below)
  • The sockets of TED and CPU should be replaced.
  • Other rusty pieces.
This Commodore 16 has seen better days

Gallery of the repair:

3 x Commodore 64 Repair

September 19th, 2019 No comments
Commodore 64 Repair

Commodore 64 repaired ASSY 250425 (1 of 3)

Defect:

  • No Video Signal.

Repair:

  • Replaced 1 x MOS 8701 R1 (U31)

Commodore 64 Repair

Commodore 64 repaired ASSY 250425 (2 of 3)

Defect:

  • Out of Memory.

Repair:

  • Replaced 1 x RAM MT 4264-15 (U21)
Commodore 64 Repair

Commodore 64 repaired ASSY 250407 (3 of 3)

Defect:

  • Garbage Screen.

Repair:

  • Replaced 1 x RAM MB 8264A-12 (U22)

Gotek (HXC) – Rotary Switch – Buzzer & Amiga 1200 OSD

September 19th, 2019 No comments
2 x Gotek (HXC) with Rotary Switch - Buzzer & Amiga 1200 OSD

The usual modification of a Gotek in HxC this time also with OSD (On Screen Display) support for Amiga 1200.

Gallery:

Video:

source: hxc2001.com

Sinclair ZX-81 Repair & Video Composite MOD (ZX8-CCB)

September 19th, 2019 No comments
Sinclair ZX-81 Repair & Video Composite MOD (ZX8-CCB)

I have received from a friend two Sinclair ZX-81 to repair and taking advantage of the “sinclair” moment :-D i have also repaired one of my ZX-81 that is died staying off for years :-(

Two out of three ZX-81 have the ULA dead, while the third had a dead membrane and some short circuits caused by someone who don’t know how to unsolder/solder properly.

I have recovered the ULA from this last one and repaired the better one of the two ZX-81, i have also installed the Video Composite mod using the ZX8-CCB kit.

I have also repaired my ZX-81 always with the ULA dead and installed the Video Composite mod using the ZX8-CCB kit.

I thank Marco Lucarelli for giving me the Video Composite mod and giving me one of the two ZX-81 (without ULA / dead Membrane and short circuits) for spare parts.

Gallery of the repair:

Amiga 600 usual electrolytic capacitors replacements

September 9th, 2019 No comments
Amiga 600 usual capacitors replacements

I have replaced all the electrolytic capacitors of this Amiga 600 motherboard.

Gallery of the repair:

Amiga 2000 CPU Socket replacement

September 9th, 2019 No comments
Amiga 2000 cpu Socket replacement (defect sometime Black Screen)

I have replaced the CPU socket of the Amiga 2000 CPU because the computer have a strange boot problems, for example: black screen.

After the replacement the problem has been gone.

Gallery of the repair:

Texas Instruments TI-99/4a Repair

September 9th, 2019 No comments
Texas Instruments TI-99-4a Repair (2019)

Texas Instruments TI-99/4a Repair.

Defects:

  • Black Screen and deafening sound in background.
  • Garbage Boot Screen.

Replaced parts:

  • 1 x SIGNETICS C2E011 ROM (U610)
  • 1 x TMS4116-15 RAM (U106)

Gallery of the repair:

Texas Instruments TI-99/4a Argentine (Spanish) Version Repair

September 9th, 2019 No comments
Texas Instruments TI-99-4a Argentine (Spanish) Version Repair

Texas Instruments TI-99/4a Argentine (Spanish) Version Repair.

Defect:

  • Black Screen and deafening sound in background.

Replaced parts:

  • 1 x TMS 9900NL CPU (U600)
  • 1 x Burned Resistor (15 Ohm)

Note: This motherboard has already been repaired by someone at least once.

Gallery of the repair:

USB Stick STM32 (Gotek) Firmware v3.4.4.6a

September 4th, 2019 No comments

Jean-François DEL NERO (who’s behind the HxC SD Floppy Emulator) recently has released a version of the HxC emulator firmware that is compatible with the STM32 chip used in the Gotek floppy emulators.

This means that the great functionality of the HxC SD emulator is now available on cheaper and more widely available hardware.

The bootloader to convert the Gotek floppy drive in HxC compatible must be purchased on the website HXC 2001 by sending an email to Jean-François DEL NERO. The price of the bootloader is one-off 10 Euro per Gotek that you want to update. Future updates of the software are free and can be made from a USB stick

The HXC Usb (Gotek) firmware supports: + many more….

USB Stick STM32 (Gotek) HxC Floppy Emulator Firmware v3.3.1.2a -> v3.4.4.6a cumulative changelog:

  • QuickDisk support : Fixes/Timing improvements. Data masked outside the read window.
  • OSD : Keys/Rotary regression fixed.
  • QuickDisk support : Various write enhancement for Roland machines support (Roland S-10,S-220,…)
  • OSD : Keys/Rotary wake-up behavior changed/enhanced.
  • QuickDisk support : More Fixes again ! Blank.qd image : Ready window increased from 5s to 5.5s
  • QuickDisk support : More important write support fixes !
  • QuickDisk support : Write support fixed (DMA descriptors fixed).
  • Work in progress : QuickDisk emulation support added !
  • A new build variant is now available to emulate QuickDisk drive !
  • The Gotek floppy port to the QuickDisk interface is:
    • – Shugart pin –          — QuickDisk Machine–
    • Pin  2 (/DC)           ->  /MS (/MediaSense)
    • Pin 10 (/DS0)          ->  Connect it to GND/VSS
    • Pin 16 (/MotorOn)      ->  /MO
    • Pin 20 (/Step)         ->  /RS (/Reset)
    • Pin 22 (/WriteData)    ->  /WD (/WriteData)
    • Pin 24 (/WriteGate)    ->   WG (WriteGate)
    • Pin 28 (/WriteProtect) ->   WP (WriteProtect)
    • Pin 30 (/ReadData)     ->   RD (ReadData)
    • Pin 34 (/Ready)        ->  /RY (/Ready)
    • Pins 4,6,8,12,14,18,26 and 32 can be left unconnected on the Gotek.
    • Odd pins Gotek pins (1,3,5,7,…,33) should be connected to the GND/VSS.
    • The jumper must be set to “MO”.
    • A Blank QuickDisk floppy disk can be found in the firmware archive in the /QuickDisk folder.
  • Fix 3.3.8.14a PC Floppy interface mode regression.
  • Faster disk-change state head-step clear and mask ready during the diskchange delay. (Fix Yamaha Clavinova diskchange issue)
  • USB stick browser : Faster/smoother files/folders browsing.
  • USB stick folder Auto mount : Faster files copy/image generation.
  • You can hide HXCSDFE.CFG, AUTOBOOT.HFE and /mount/emptyfat.img files on the stick now.
  • Default 7 segments screen standby / powerup can changed on the custom firmware page : https://hxc2001.com/custom_fw/
  • Fix non-working v3.3.6.1a firmware !
  • On screen display : Separated HSYNC/VSYNC signals support added:
    • For machines without CSYNC (Composite Sync) signal.
    • Once this option is enabled the Gotek video IOs are mapped as this :
    • OSD Video out : Gotek U8 Pin 5 (PB15).
    • OSD Video HSYNC in : Gotek “JTCK-SWCLK” pin (PA14).
    • OSD Video VSYNC in : Gotek U8 Pin 1 (PB12).
  • New system family raw file support : Roland W30/W50/S50/S330/S550. (7 digits display menu entry -> 019)
  • Fix floppy IO pins state when the select line is permanently low (v3.3.4.1a regression).
  • Write codes speed optimizations.
  • HFE : Format support : Fix the “too early index” issue.
  • Raw files : Fix interface mode settings. (v3.3.4.4a regression)
  • File sorting : Ignore file name case.
  • Direct access : Fix the “set index” command.
  • OSD : CSYNC Pull-up enabled.
  • Fix some possible format issues.
  • Some more optimizations.
  • Head settling time default value fixed on the custom firmware page : https://hxc2001.com/custom_fw/
  • “Interface CFG” LCD/OLED/OSD menu entry fixed.
  • OSD:
    • Code speed optimizations (CPU pipeline + Flash prefetch optimizations).
    • OSD Polarity can be now set with the “OLED screen polarity” parameter.
  • Better/lower lines jitter while floppy emulation is running.
  • USB : Code speed optimizations (read & write Fifos, ISR).
  • ASM ISR (Step, Drive Select…) : Many code speed optimizations (CPU pipeline + Flash prefetch optimizations).
  • The firmware is now stable with both OSD and floppy emulation working in the same time !
  • “Normal mode” / Direct disk browsing : Files entries are now alphabetically ordered. Folders appears first then the files images.
  • “Load Last selected image” : Fix reload issue with some long file names.

This is only a little part of the changelog. The original one is very long and you can read it here. (instruction manual here)

The HxC Floppy Emulator Firmware Customization page: https://hxc2001.com/custom_fw/

Download: USB Stick STM32 (Gotek) HxC Firmware v3.4.4.6a (879)

source: hxc2001.com

Categories: Firmware, News & Rumors, Today

Pocket-Go / LDK Game (Landscape ver.) Retro Gaming Handhelds

August 24th, 2019 No comments
Pocket-Go (Bitt-Boy Landscape version) / LDK Game (Landscape version)

Pocket-Go (Bitt-Boy Landscape version) / LDK Game (Landscape version) Open Source Retro Gaming Handhelds.

I’m always been fascinated by these small retro gaming handhelds consoles especially for the low cost.

These small consoles emulate quite well most games of consoles and computers and are supported by an active community of enthusiasts.

I don’t think it’s necessary to do the hundredth review of these portable consoles, i leave you with the technical specifications of each consoles and some useful links.

LDK Game Retro Gaming Handheld Technical (Landscape Version) Details:

  • Processor: JZ4760B Dual-Core 64Bit 528Mhz
  • Software Functions: Retro Gaming Emulation, Audio/Video Playback, Audio Recorder, E-Book.
  • Pre-Installed Emulators: CPS1, CPS2, Neo-Geo, Megadrive / Genesis, Sega Master System, GameGear and so on.
  • Display: 2.7″ Inch Color Display (TFT) Adjustable screen brightness.
  • Resolution: 320×240.
  • Video Playback: Supports the following formats: RM, RMVB, AVI, MKV, WMV, VOB, MOV, FLV, ASF, DAT, MP4, 3GP, MPG, MPEG
  • RAM: 128MB DDR2.
  • Storage: 16GB Fast-Accessing Storage.
  • Storage Expansion: Micro SD Card Slot (For up-to 128GB)
  • Speakers: High Quality – Built IN.
  • Analog Stick.
  • Audio Playback: Supports the following formats: APE, MP3, WMA, DRM WMA, OGG, APE, FLAC, WAV, AAC (Including: AAC-LC/AAC HE/AAC+V1/V2)
  • Audio Recording: Supports Audio Recording in .WAV (High Quality)
  • I/O: RCA Component for TV Output, 3.5mm Headphone Jack, Micro USB Port, Micro SD Card/TF Card Slot.
  • Languages: Multi.
  • Battery: Li-Ion BL-5C 1020mAh Built-in.
  • Dimensions (cm): 12.9 x 8.8 x 1.7
  • Package: Consoles, USB Cable, USB-SD Card Adapter, User Manual, 32GB SD Card.

Link:

Pocket-Go (Bitt-Boy Landscape version) OpenDingux Technical Details:

  • Processor: ALLWINNER F1C100S ARM9 up to 900MHz
  • Software Functions: Retro Gaming Emulation, Audio/Video Playback, Audio Recorder, E-Book
  • Pre-Installed Emulators: CPS1, CPS2, Neo-Geo, Megadrive / Genesis, Sega Master System, GameGear and so on.
  • Display: 2.4″ Inch Color Display (IPS) Adjustable screen brightness with a tempered glass protector for the screen will effectively reduce the problem of screen scratching.
  • Resolution: 320×240.
  • Video Playback: Supports the following formats: RM, RMVB, AVI, MKV, WMV, VOB, MOV, FLV, ASF, DAT, MP4, 3GP, MPG, MPEG
  • RAM: 32MB DDR2
  • Material: ABS
  • Memory card type: Micro SD
  • Storage: supported up to 128GB
  • Speakers: High Quality – Built IN
  • Audio Playback: Supports the following formats: APE, MP3, WMA, DRM WMA, OGG, APE, FLAC, WAV, AAC (Including: AAC-LC/AAC HE/AAC+V1/V2)
  • Audio Recording: Supports Audio Recording in .WAV (High Quality)
  • I/O: RCA Component for TV Output, 3.5mm Headphone Jack, Micro USB Port, Micro SD Card/TF Card Slot
  • Extra: Support vibration on games.
  • L,R Buttons.
  • Battery: 1000mAh lithium battery
  • Languages: Multi.
  • Battery lasts 3–4 hours
  • Dimensions (cm): 12.3 x 5.6 x 1.4
  • Package: Consoles, USB Cable, USB-SD Card Adapter, User Manual, 8GB SD Card, Nintendo Style Buttons Replacements.

Link:

Gallery:

Categories: Hardware, News & Rumors, Today

Hoxs64 Commodore 64 Emulator Updated v1.0.21.2

August 20th, 2019 No comments

Hoxs64 written by David Horrocks is a Commodore 64 emulator for Microsoft Windows 2K/XP/Vista/Seven (DirectX 9+)

The emulator substantially reproduces this legacy machine in minute detail.

Changelog (v1.0.21.2):

  • Changed command line option -autoload “hostfilename.d64″ “:c64filename” such that c64filename will have the case flipped.
  • Added command line option “@” to index a directory with no file type filter.

Download:

source: hoxs64.net

Released the latest version of DiagROM v1.2 for Amiga

August 18th, 2019 No comments

What is DiagROM?

DiagROM is a diagnostic tool for the amiga computers.

And it is to be used on defective machines, trying to help no-boot situations etc.

You simply replace the Kickstart roms in the Amiga with the DiagROM. and when poweron. your Amiga will start a diagnostic software. It will try to dump info on the serialport (and actual menus etc aswell) while also trying on the screen.

Changelog:

  • Now Diskdrivetest should work on most machines.
  • Memchecks should now detect non working ram better.
  • Experimental CIA test added that should work on NTSC machines aswell. MIGHT give false results on TOD-B  tests. It will still say that IRQ is needed, this is not true :)
  • Added RGB Test.
  • Usual “bugfixes” pressing left mousebutton when chipmemdetect starts skips serial output and makes startup faster. holding down left mousebutton while doing memscan at start skips memtests. (good if it hangs during scan. known not found bug yet!)
  • Updated to tested values if new CIA test that should be more correct.
  • Also in memoryedit mode (memtest) added pageup/down functions with Q and Z keys.
  • (or Amigastandard shift+cursor keys)  also added official support to execute code from current locaton using the X key. (this is very much not really useful for most people)

Download: DiagoROM v1.2 Stable (756)

source: diagrom.com

Categories: Firmware, News & Rumors, Today
