Computer MSX Keyboard Membrane Repair

June 30th, 2016 No comments
MSX Keyboard Membrane Repair

I used a product to regenerate the rubber keypad of remote controls to repair the keyboard flat cable of a Home Computer MSX.

I have used this product many times for my work of Retro Computer restoration but never to regenerate the rubber keypad of remote controls :D

Gallery of the repair:

2 x Commodore Amiga 500 Keyboard Repair

June 30th, 2016 No comments
Commodore Amiga 500 Keyboard Repair

Keyboard #1

Defect:

  • When the keyboard is connected, the computer doesn’t work (black screen)

Components replaced:

  • 1 x 74LS132P (U4)

Keyboard #2

Defect:

  • The Caps lock flashes three times and the keyboard doesn’t work.

Fix:

  • Cold solder joint on the capacitor (C11)

Gallery:

C64 Big Game Pack: Deja Vu & Uninvited +1DW / Valhalla +3DMS …

June 29th, 2016 No comments

Some new games or tools (Cracked / Trained or Unrealeased) for Commodore 64 have been released from your favorites groups.

Titles:

  • QWAK 1.2 +4H
  • QWAK 1.2 16K Compo Final
  • QWAK 16K V1.2 +4HF
  • Evil Garden +4D
  • Scout +5DGH
  • Ghosts’n Goblins Arcade / Commando Arcade SE / Bruce Lee II [easyflash] [bugfixed]
  • Munch Load +M
  • Zorro in Wonderland 2 Preview
  • Color Code
  • Sea Slug +3D
  • Honey Bee [real sales version] +6D
  • Challenge of the Gobots on the Moebius Strip +5DGH
  • Deja Vu & Uninvited +1DW [easyflash]
  • Excalibur +
  • Ocean Ranger [1581,FD,HD]
  • Mission Odessa +2DTS
  • Excalibur
  • The Curse of Sherwood +26D
  • V.I.O.S. (Special Edition 2011) +2 [seuck]
  • Estados of Brasil
  • States of Brazil
  • Kabura
  • Gunslinger [1581,FD,HD]
  • Valhalla +3DMS
  • Tycoon Tex Preview +2
  • Dorks Dilemma Preview +2
  • Kabura +2T
  • The Crown of Ariiance
  • Breakaway
  • Super Jumpkick Preview

Download: All Games in One Archive (530)

source: csdb.dk

CBM prg Studio v3.8.0 released

June 18th, 2016 No comments

CBM prg Studio Version 3.5.0 is released. There are a lot of new features in this version. I’d really appreciate it if you report any bugs you find or have any suggestions/comments.

CBM prg Studio allows you to type a BASIC or Machine Code program in using a nice Windows environment and convert it to a ‘.prg’ file which you can run on an emulator, or even a real C64 / VIC20 or PET if you’re feeling brave and have the right kit.

CBM prg Studio is the result of merging C64PrgGen and VIC20PrgGen. Adding new features and fixing bugs in two apps which were 95% similar was a bit of a nightmare so merging them made sense.

It was also a good opportunity for a face lift and to add some new features, such as:

  • Programs are project based, meaning all related source files, sprite files etc. are kept in one place and multiple source files can be linked more easily.
  • Tabbed MDI.
  • Syntax highlighting.

What CBM prg Studio isn’t is a front-end for tok64, cbmcnvrt, bastext or any other tokeniser / detokeniser / assembler. It’s all been written completely from scratch.

New features in v3.8.0:

  • Assembler:
    • Logical operators.
    • Code relocation.
    • Watch labels/addresses.
    • Local character mapping.
  • Screen Editor:
    • More export options.
    • Change border colour.
  • Sprite Editor:
    • Multiple layers for preview.
    • Invert sprite.
  • General:
    • Load VICE palettes.
    • Open a command line.

Bugs Fixed:

  • General:
    • Remember ‘close start page’ state.
  • Sprite editor:
    • Imported sprites had the same data.
    • Select mode on scratch pad didn’t work.
  • Screen code builder:
    • Left arrow generated wrong code.
  • Character editor:
    • Export characters as hexadecimal.
    • Multicolour chars flip left/right not working.

See the help for a complete list of new features and fixed bugs.

Note In this version, each target machine can have its own default project directory. If you are upgrading from a previous version (before version 2.5.1) of CBM prg Studio you may be asked to set up your project directories again. Your current projects will not be affected.

Download: CBM prg Studio v3.8.0 (340)

source: ajordison.co.uk

Processor Technology SOL-20 Analysis & Repair

June 15th, 2016 No comments
Processor Technology SOL-20 Analysis & Repair #2

Below the description of the repairing of two Processor Technology SOL-20.

Processor Technology SOL-20 #1 Repair

Defect:

  • Dead/Split Screen.

First of ALL!

  • You should never replace CD4029 with HCF4029 although apparently could work and maybe it works .. on some motherboard could do bizarre defects or video glitches, like a split screen!

Components replaced and fixes:

  • Replaced all IC series HCF 4XXX HCF with the right CD 4XXX series.
  • Sprayed DUE-CI G-22 on all Texas Instruments IC sockets.
  • Replaced wrong ic 74LS157 in place of a 74LS367 (U29)
  • Rebuild broken pcb track near the caps (C15)
  • Replaced wrong capacitor of 22uf in place of a 1uf (C67)
  • Rebuild  bridges under the IC U46 that has seen better days.
  • Replaced Capacitor (C31)
  • Remake cold welding on the PSU connector and the socket of CPU Intel 8080A.
  • Removed a little piece of solder under a socket (see photo)
  • Replaced 74LS138 (U34) dead without reason while typing this text on the SOL-20 (FUCKKKK!!!!!!!!!)

… Some Beers… :-D

Gallery of the repair:

Processor Technology SOL-20 #2 Repair

Defect:

  • Black Screen/Dead.

First of ALL!

  • You should never replace CD4029 with HCF4029 although apparently could work and maybe it works .. on some motherboard could do a bizarre defects or video glitches!

Components replaced and fixes:

  • Replaced all IC series HCF 4XXX HCF with the right CD 4XXX series.
  • Sprayed DUE-CI G-22 on all Texas Instruments IC sockets.
  • Cleaned the motherboard and connectors with Kontakt PCC (Printed Circuits Cleaner)
  • Temporarily removed the IC 74LS136 (U22) which put in short-circuit the personality card and burned the 74LS04 (U24). Probably this is a “homebrew” modification for a particular Personality card.
  • Replaced wrong ic 74LS04 (U23) in place of a 74LS20 (U23)
  • Replaced RAM 2102 (U15)

Note:

  • Many sockets not of the Texas Instruments completely rusted are previously been replaced by the owner of this computer (Alessandro Polito).

Gallery of the repair:
